Design and Development of a PAMSIMAS Water Consumption Monitoring System Prototype Using a Smart Water Meter and LoRa
DOI:
https://doi.org/10.65359/6rew7f55Keywords:
PAMSIMAS, Smart Water Meter, Internet of Things (IoT), LoRa, Flow Sensor, Turbidity SensorAbstract
The main problem in the PAMSIMAS water management system is the continued use of manual recording methods, which may lead to recording errors, delayed information, and the absence of a real-time monitoring system. This study aims to design and develop an Internet of Things (IoT)-based water usage monitoring system using a flow sensor to measure water flow rate and volume, and a turbidity sensor to measure water turbidity. The data are processed using an ESP32 microcontroller and transmitted through a LoRa module to a gateway for display on a web-based monitoring dashboard. The test results show that the LoRa RA-02 communication system achieves an optimal range of approximately 250–300 meters under line-of-sight (LOS) conditions in open areas, but its performance decreases in environments with physical obstacles. Thirteen flow sensor tests resulted in an average error of 1.44%, corresponding to an accuracy of 98.56%, which is below the commonly used tolerance limit of 5%. Meanwhile, the turbidity sensor was able to detect water quality effectively, with test readings of 45.06 NTU (very clear) and 315.02 NTU (turbid), and was able to classify water conditions according to the applicable Indonesian Ministry of Health standards. Based on these results, the developed system is capable of monitoring water usage and quality in real time with adequate accuracy and efficiency. The system is expected to assist PAMSIMAS managers in improving the efficiency, transparency, and quality of clean water distribution services to the community.
Downloads
References
A. Hamid, H. Yelmi, I. Fadhillah, and R. Putra, “Evaluasi Tingkat Kecukupan Pasokan Air PAMSIMAS Pokmas Tambiliok Jaya Desa Muara Jalai dan Ketepatan Distribusinya Bagi Warga Masyarakat Sekitar,” vol. 3, no. September, 2025.
D. Nabila, N. Pangestu, and U. Semarang, “PENGENDALIAN DAN MONITORING KUALITAS AIR PADA BAK PENAMPUNGAN BERBASIS INTERNET OF THINGS (WATER QUALITY CONTROL AND MONITORING IN STORAGE BASED ON INTERNET OF THINGS ) Deti Nabila Novi Pangestu,” pp. 1–9, 2023.
F. Rahmansyah and P. Murdiyat, “Rancang Bangun Sistem Monitoring Pertanian Cerdas Berbasis LoRa Untuk Pemantauan Kondisi,” vol. xx, no. xx, pp. 50–62, 2025.
H. T. Abueltayef, K. S. Abualhin, and K. M. Alastal, “Addressing non-revenue water as a global problem and its interlinkages with sustainable development goals,” Water Pract. Technol., vol. 18, no. 12, pp. 3175–3202, 2023, doi: 10.2166/wpt.2023.157.
http://transukma.uniba-bpn.ac.id/index.php/transukma/article/view/68
J. R. Ilmiah, P. Sistem, P. Kebakaran, R. Peringatan, D. Menggunakan, and T. Lora, “SENTRI :,” vol. 4, no. 12, pp. 4446–4464, 2025.
M. Danu, F. Mawasandi, Z. N. Aziz, and M. F. G. Rosyadi, “Transformasi Manajemen Rantai Pasokan Berbasis Internet of Things ( IoT ): Tinjauan Literatur,” vol. 4, no. 1, pp. 32–44, 2025.
M. K. Lora, I. Irmayani, E. Nadine, and M. F. Abdillah, “Perancangan dan Implementasi Sistem Monitoring Peminjaman Arsip Berbasis ESP32,” no. 2, pp. 1–11, 2025.
M. Kautsar, R. R. Isnanto, and E. D. Widianto, “Sistem Monitoring Digital Penggunaan dan Kualitas Kekeruhan Air PDAM Berbasis Mikrokontroler ATMega328 Menggunakan Sensor Aliran Air dan Sensor Fotodiode,” vol. 3, no. 1, 2015.
Mustakim and D. T. Pratama, “Analisis Non Revenue Water (NRW) Pada Jaringan Pipa Air Bersih PDAM Kota Balikpapan,” J. Penelit. TRANSUKMA, vol. 03, no. 1, pp. 25–33, 2020, [Online]. Available:
N. Ainaini and R. Dewi, “Efektivitas Penyaluran Penyediaan Air Minum dan Sanitasi Berbasis Masyarakat (PAMSIMAS) di Desa Tabing Kecamatan Koto Kampar Hulu Kabupaten Kampar,” vol. 2, no. 1, pp. 13–22, 2025.
N. Muamaroh and W. Christanto, “Pengukur Penggunaan Air Otomatis Menggunakan WaterFlow Sensor YF-S201 Dan NodeMCU ESP8266 Berbasis IoT IoT Based Automatic Water Usage Measurement System Using YF-S201 WaterFlow Sensor and NodeMCU ESP8266,” no. 1, pp. 88–99, 2024, doi: 10.26798/jiko.v8i1.1104.
N. Yadi, M. Belladona, and E. Dwiantoro, “Analisa Tingkat Kehilangan Air (Water Losses) pada Jaringan Distribusi PDAM Tirta Hidayah Zona 3 Kota Bengkulu Tahun 2024,” RIGGS J. Artif. Intell. Digit. Bus., vol. 4, no. 3, pp. 2280–2290, 2025, doi: 10.31004/riggs.v4i3.2302.
P. K. Mental, L. An-nisa, I. A. Farida, N. Eva, D. A. Apsari, and H. B. Utomo, “Implementasi Model ADDIE dalam Media Edukasi sebagai,” vol. 18, no. 1, pp. 41–46, 2025, doi: 10.35134/jpsy165.v18i1.466.
V. K. Bakti, Abdul Basit, Rais, and Wiwit Suryanto, “Sistem Monitoring Kapasitas dan Kualitas Air dengan Metode SWAT (Smart Water Meter) menggunakan Protokol Lora berbasis IoT,” Komputika J. Sist. Komput., vol. 14, no. 1, pp. 1–9, 2025, doi: 10.34010/komputika.v14i1.15051.
Vinchi et al., “Pemanfaatan Iot Untuk Pemantauan Debit Air,” vol. 13, no. 3, 2023.
